2U Server - Dual Processor - 48V DC Power

This 2U Short-Depth Server features Dual Intel Xeon Scalable processors, offering up to 32 cores and 2TB of DDR4 ECC Registered memory. With a compact 18-inch depth and 48V DC power supply, it's ideal for Maritime, Vehicle, Telecom and Data Center applications requiring high performance in space-constrained environments.

Key Features
  • Short Depth
  • Front USB
  • 48v DC Power
  • Video (HD Output)
  • 18-Inch deep
  • Dual LAN
  • Dedicated IPMI / iKVM
  • TPM 2.0
Related Tags
Samsung 980
Samsung 970 PRO
Samsung 980 PRO
Samsung 980
Samsung 990 EVO
Samsung 990 PRO
WD_BLACK™ SN850X
Samsung 870 EVO
Solidigm-SKHynix D3-S4520 (formerly Intel)
Solidigm-SKHynix D3-S4620 (formerly Intel)
Western Digital® Enterprise-class
Microsoft®
Special Order

Tech Specs

Chassis
  • 2U Short-depth Rack Mountable Enclosure (LOW-PROFILE)
  • Rack Unit Height: 3.5-inch
  • Dimensions: 17.7" (D) x 19" (W) x 3.5" (H)
  • Metal thickness: 1.2 mm
  • Front Single Door with 2 Thumbscrews
  • Air Filter Inside Front Panel (Washable)
  • Front USB: 2 x ports
Processor/Chipset
  • Dual Socket LGA-4189 (Socket P+)
  • Supports 3rd Gen. Intel® Xeon® Scalable processors
  • Intel® C621A chipset
BIOS
  • AMI UEFI
Memory
  • 8 x DDR4 DIMM sockets
  • Supports up to 2TB
  • DDR4 3200/2933MHz ECC 3DS, LRDIMM, RDIMM
Storage / IPMI
  • 12 x SATA3 (6Gbps) ports
  • Intel® C621A controller on-board
  • IPMI 2.0 support (ASPEED AST2600 BMC)
  • Chassis supports up to three drives
  • 2 x M.2 NVMe 2280/22110
Drive Bays
  • HD1-3 Bay: fixed SATA/ SSD Drive
  • Up to 72 Terabyte of storage can be supported
  • 1 x 5.25-inch Drive Bay
I/O ports
  • 2 x RJ45 Gigabit Ethernet LAN ports
  • 5 x USB 3.2 Gen.1 ports (2 x via header, 2 x rear; 1 x type A)
  •
  • 1 x VGA port
  • 1 x COM Port (1 x header)
  • 1 x TPM Header
  • 2 x SATA DOM power connectors
Video
  • ASPEED AST2600 BMC Graphics on-board

Network
  • Dual LAN with Intel® i210 Gigabit Ethernet Controller
Hardware Monitor
  • CPU/System Fan Speed
  • CPU Temperature
  • System Voltage Vcore,+3.3V,+5V,+12V
Expansion (LOW-PROFILE)
  • 4 x PCI-e 4.0 (x16) slots
Power Consumption/Acoustic noise emission
  • Dependent upon hardware configuration.
  • Please contact our tech support at 714-258-2269 for further details.
Power Supply
  • 48V DC Power Supply
  • Voltage range: -36 ~ -72 VDC
  • Voltage normal: -48VDC
  • Steady-state current: -36 ~ -72 VDC / 25~10 amp (16 amp at -48VDC)
  • Inrush current: 50 amps @ -48VDC (at 25C ambient cold start)
  • Tested to comply with FCC Standards
  • Redundant 48V DC Power Supply is OPTIONAL
CD-ROM /DVD-ROM
  • 5.25-inch Optical Drive OPTIONAL
Rack Support
  • 2U rackmount rails kit is OPTIONAL
OS Compatibility
  • Please call our tech support at 714-258-2269 for details
Warranty
  • 3 years Parts* and Labor Standard
  • * Batteries are subject to DOA only and are NOT subject for replacement or return
  • Extended Warranties Available
Large Image

OS Compatibility

Motherboard X12DPL-i6 OverallChipset
Intel C621A		LAN
Intel I210		Video
ASPEED AST2600
CentOS 9
Debian 12
Fedora Server 41
Fedora Workstation 41
FreeBSD 14

DISCLAIMER: We strive to provide accurate and current compatibility information. However, due to the rapidly evolving nature of technology and software, we cannot guarantee complete compatibility. The information presented here reflects only the known issues identified by our team. If you discover additional challenges or potential solutions, please let us know so we can continuously enhance this resource for everyone.
